Parking Lot High Power 4000K 80W IP66 LED Flood Light

Name: Parking Lot High Power 4000K 80W IP66 LED Flood Light
Brand: LCD-CESP
Price: 1 USD

Quality Parking Lot High Power 4000K 80W IP66 LED Flood Light wholesale

Brand Name : LCD-CESP

Model Number : LCD-HB-S3-085-LNXX

Certification : CE RoHs SAA ETL UL TUV

Place of Origin : SHENZHEN, CHINA

MOQ : 1pcs

Price : usd

Supply Ability : 5000pcs/ month

Delivery Time : 5-12 work day

Packaging Details : Carton box

Led light source : SMD 5050

Frequency Range : 50-60HZ

Power Factor : >0.95

Power Efficiency : >90%

Total Power : 50W 80W 100W 150W 200W

Lamp luminous flux(lm) : 7,750 lumen to 31,000 lumen

Contact Now

Parking Lot High Power 12000 Lumen 80W IP66 LED Flood Light

Die cast Aluminum alloy housing 12000 lumen waterproof IP66 LED Flood Light 80W

Product family details

Ambient Temperature	-30 to +45 °C
Main color of the Luminaire	Dark gray
Beam spread luminaire	30° 60° 60° 60° 100° 120°
Initial correlated color temperature	4000K, 5000K, 6500K
Luminous Efficiency	140LM per watt
Input frequency	50 to 60 Hz
Input voltage	220-240 V
Light source color	840 neutral white, 865 cool daylight
Material	Housing: aluminum die-cast
Material	Cover: polycarbonate, flat
Median Useful Life L70B50	50000 h

Looking for a low cost LED high bay?

Well here it is! The HB-S3 is one of the brightest lights on the market today. Competitors offer similar fixtures.

Model	LCD-HB-S3-055	LCD-HB-S3-085	LCD-HB-S3-105	LCD-HB-S3-125	LCD-HB-S3-155	LCD-HB-S3-205
Lumens	7,500 lm	12,000 lm	15,000 lm	18,000 lm	22,500 lm	30,000 lm
Power	50W	80W	100W	120W	150W	200W
Comparable HID or Metal Halide	150W	250W	350W	400W	500W	650W

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Applications
・Container/ terminal lighting (High-mast lights)
・Apron floodlighting for Airport
・Car park (High-mast lights)

Parking Lot High Power 4000K 80W IP66 LED Flood Light

HB Family

TyPE	LCD-HB-S3-055-LNXX	LCD-HB-S3-085-LNXX	LCD-HB-S3-105-LNXX	LCD-HB-S3-125-LNXX	LCD-HB-S3-155-LNXX	LCD-HB-S3-205-LNXX
Luminous Flux	7,500 lm	12,000 lm	15,000 lm	18,000 lm	22,500 lm	30,000 lm
Lens	30º narrow	30º narrow	30º narrow	30º narrow	30º narrow	30º narrow
Power consumption	50W	80W	100W	120W	150W	200W
Color Temperature	3000K	4000K	6500K	3000K	4000K	6500K
Color Rendering	Ra>75	Ra>75	Ra>75	Ra>75	Ra>75	Ra>75
Input Voltage	AC100-277V	AC100-277V	AC100-277V	AC100-277V	AC100-277V	AC100-277V
Frequency	50-60 Hz	50-60 Hz	50-60 Hz	50-60 Hz	50-60 Hz	50-60 Hz
Main Body	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy	Aluminum Alloy
Outer lens	PC with Anti-UV & Hard-coating	PC with Anti-UV & Hard-coating	PC with Anti-UV & Hard-coating	PC with Anti-UV & Hard-coating	PC with Anti-UV & Hard-coating	PC with Anti-UV & Hard-coating
Exterior Painting	Heavy-duty salt resistant paint	Heavy-duty salt resistant paint	Heavy-duty salt resistant paint	Heavy-duty salt resistant paint	Heavy-duty salt resistant paint	Heavy-duty salt resistant paint
Mount Type	Adjustable bracket & eye bolt	Adjustable bracket & eye bolt	Adjustable bracket & eye bolt	Adjustable bracket & eye bolt	Adjustable bracket & eye bolt	Adjustable bracket & eye bolt
Operating Temperature	-30º--+50°	-30º--+50°	-30º--+50°	-30º--+50°	-30º--+50°	-30º--+50°
Rated Life (L70)	50,000h	50,000h	50,000h	50,000h	50,000h	50,000h
IK rate	IK09	IK09	IK09	IK09	IK09	IK09
Surge protection	2-4Kv(normal mode) 10KV(on requests)	2-4Kv(normal mode) 10KV(on requests)	2-4Kv(normal mode) 10KV(on requests)	2-4Kv(normal mode) 10KV(on requests)	2-4Kv(normal mode) 10KV(on requests)	2-4Kv(normal mode) 10KV(on requests)

LIGHTING PERFORMANCES

Product dimension

Installation

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Packing data
